During the manufacturing process of shelves, the surface spray coating of warehouse shelves refers to using solid powder coatings instead of liquid solvent-based coatings. The powder coatings are negatively charged by high voltage and then adsorbed onto the surface of the grounded workpiece by means of electrostatic attraction. After being heated and melted (or cured), a coating film is obtained. Electrostatic spray coating is a new process. The powder coatings used do not contain liquid components such as solvents and dispersion media. They do not need to be diluted or have their viscosity adjusted when in use. They cannot flow on their own and can only flow after being melted. They cannot adhere to the workpiece surface like liquid coatings do.
The electrostatic spraying of powder coatings on warehouse shelves is called spray coating. Its principle is to make the powder coatings adhere to the workpiece by utilizing the corona discharge phenomenon. In the spray coating process of warehouse shelves, the powder coatings are sent into the spray gun by the powder supply system with the help of compressed air. High voltage generated by a high-voltage electrostatic generator is added at the front end of the spray gun. Due to corona discharge, dense electric charges are generated nearby. When the powder is sprayed out from the nozzle of the gun, it forms charged coating particles. Under the action of electrostatic force, these particles are attracted to the workpiece with the opposite polarity. As more powder is sprayed on, more electric charges accumulate. When a certain thickness is reached, due to the electrostatic repulsion effect, the powder will no longer be adsorbed, so that the entire workpiece obtains a powder coating with a certain thickness. Then, through high temperature, the powder is melted, leveled, and cured, and a hard coating film is formed on the surface of the workpiece.
There are many advantages of electrostatic spray coating for warehouse shelves. In summary, the main ones are as follows:
- No thinners are required. The construction process causes no pollution to the environment and is harmless to human bodies.
- The appearance quality of the coating is excellent, and its adhesion and mechanical strength are strong.
- The curing time during the spraying construction is short.
- The corrosion and wear resistance of the coating is much higher.
- No primer is needed.
- The construction is simple, and the technical requirements for workers are low.
- The cost is lower than that of the painting process with the same effect.
- In some application scenarios, it has been clearly required that the electrostatic spray coating process must be used.
- The phenomenon of flowing, which is common in the painting process, will not occur during the electrostatic powder spraying process.
- The spraying effect is superior to that of the painting process in terms of mechanical strength, adhesion, corrosion resistance, and aging resistance.
- It has developed rapidly. Besides various effects such as hammer finish, orange peel finish, frosted finish, high-gloss finish, matte finish, crackle finish, glitter gold, glitter silver, etc., in recent years, high-temperature-resistant powders, low-temperature-resistant powders, high-weather-resistant powders, water-resistant powders, acid-resistant powders, low-temperature-curing powders, UV-curing powders, etc. have emerged one after another, making electrostatic powder spraying have a broader prospect.
Therefore, the electrostatic spray coating technology applied to warehouse shelves has the characteristics of high coating efficiency, excellent coating film performance, no solvent evaporation, little environmental pollution, low energy consumption, short production cycle, and being easy to realize coating automation.
According to relevant reports, along with the increase in the total output and transportation volume of meat, frozen foods, cold drinks, dairy products, aquatic products, vegetables, and fresh fruits, the market demand for warehouse shelves will continue to increase in the next few years.
